QUESCAN G10A-F30 UBX M10 ГПС-модуль 1-25 Гц ГНСС-приемник для FPV-дрона Betaflight ГПС ГЛОНАСС Галилео Бэйдоу QZSS SBAS

<div class="detailmodule_text-image"><p style="font-family:OpenSans;font-size:20px;font-weight:900;line-height:28px;white-space:pre-wrap;color:rgb(0, 0, 0);margin-bottom:12px" class="detail-desc-decorate-title"><span style="font-size:22px;font-family:arial, helvetica, sans-serif">Overview</span></p><p><span style="font-size:20px;font-family:arial, helvetica, sans-serif">G10A-F30 module features the UBX M10 standard precision GNSS platform and provides exceptional sensitivity and acquisition time for all L1 GNSS signals.

G10A-F30 is a highly cost-effective GNSS L1 solution.

G10A-F30 supports a maximum positioning update rate of 25Hz (need to be configured in high-performance mode).</span></p><p><span style="font-size:20px;font-family:arial, helvetica, sans-serif">The M10 platform supports concurrent reception of four GNSS (GPS, GLONASS, Galileo, and BeiDou) with QZSS SBAS enbale.

The high number of visible satellites enables the receiver to select the best signals.

This maximizes the position availability, in particular under challenging conditions such as in deep urban canyons.</span></p><p><span style="font-size:20px;font-family:arial, helvetica, sans-serif">UBX Super-S (Super-Signal) technology offers great RF sensitivity and can improve the dynamic position accuracy with small antennas or in non-line-of-sight scenarios.</span></p><p><span style="font-size:20px;font-family:arial, helvetica, sans-serif">G10A-F30 module supports NMEA and UBX protocol input and output.

It is recommended to use UBX-NAV-PVT statement under UBX protocol, which is widely used in various controllers.
