3 in 1 Diagnostic Post Card USB Mini pci-e PCI E PCI LPC PC Analyzer Tester pci express Tester adapter For Notebook Express Card

<p><span style="font-size:26px"><strong>Features:</strong></span></p><p><br/></p><p><strong>Interface: mini PCI, mini PCI-E, LPC</strong></p><p><br/></p><p><strong>Suitable for laptop</strong></p><p><br/></p><p><strong>Support Mini PCI, Mini PCI-E, LPC bus interface</strong></p><p><br/></p><p><strong>The laptop motherboard wil output a series of fault codes in the process of working.</strong></p><p><br/></p><p><strong>The disgnostic card will receive these fault codes.</strong></p><p><br/></p><p><strong>The users can determine the fault of the motherboard through the fault codes.</strong></p><p><br/></p><p><strong>It is note universal.</strong></p><p><br/></p><p><strong>RST indicator is off, CLK indicator doesn&#x27;t flash and the code of the diagnostic card is &quot;00&quot;.</strong></p><p><br/></p><p><strong>It shows that the card does not receive the clock signal and can not work.</strong></p><p><br/></p><p><strong>Maybe the motherboard does not support the diagnostic card mini PCI-E interface.</strong></p><p><br/></p><p><strong>Please use the LPC interface or mini PCI interface for testing.</strong></p><p><br/></p><p><strong>RST indicator is off, CLK indicator flashes and the code of the diagnostic card is &quot;00&quot;.</strong></p><p><br/></p><p><strong>It shows that the RST and clock signal is normal.</strong></p><p><br/></p><p><strong>Please check the Bus indicator.</strong></p><p><br/></p><p><strong>If the lower-right corner of the right digital tube is on, it shows that diagnostic card is in mini PCI-E or LPC bus state.</strong></p><p><br/></p><p><strong>If the lower-left corner of left is on, it shows that the diagnostic card is in mini PCI bus state.</strong></p><p><br/></p><p><strong>Usually, the motherboard has no slot corresponding with the interface.</strong></p><p><br/></p><p><strong>So the users need to connect the interface to the motherboard through the flying line.</strong></p><p><br/></p><p><strong>Generally, for convenience, it is recommended that the user connects the diagnostic card to LPC interface BIOS through the flying line on the motherboard.</strong></p><p><br/><br/></p><p><span style="font-size:26px"><strong>Please don&#x27;t insert the PCI-E to the PCI slot.</strong></span></p><p><br/></p><p><strong>1 x Diagnostic card</strong></p><p><br/></p><p><strong>1 x User manual</strong></p><p><br/></p><p><img src="https://ae01.alicdn.com/kf/Se2cd6d647e814c44a0e84e6a932cfddbK.jpg" slate-data-type="image"/><img src="https://ae01.alicdn.com/kf/S31554803d7d54ba499ecb0e5e3aa1be95.jpg" slate-data-type="image"/><img src="https://ae01.alicdn.com/kf/S412f11f26bb547ceaaf1ffd386f7dfabf.jpg" slate-data-type="image"/><img src="https://ae01.alicdn.com/kf/S020f86855b664da9917fa258471d5d48n.jpg" slate-data-type="image"/><img src="https://ae01.alicdn.com/kf/S24c62f2691324c9ca5b9577a7efea921t.jpg" slate-data-type="image"/><img src="https://ae01.alicdn.com/kf/S741cbb221a20467a92b0f125c8f6ad37I.jpg" slate-data-type="image"/><img src="https://ae01.alicdn.com/kf/S827cc1eeac6f4241a122837e22f3deb5R.jpg" slate-data-type="image"/><img src="https://ae01.alicdn.com/kf/S9a382a86b26547a2b17c75b61dd3f5437.jpg" slate-data-type="image"/><img src="https://ae01.alicdn.com/kf/Sbddda3d50e424382b819e436f2f0d2afL.jpg" slate-data-type="image"/></p>
